Moon images July and August 2017
  • Mosaic images July + August 2017
The following images show moon mosaic images taken in July and August 2017. All images were taken with the C14 of the Onjala Observatory. All pictures - except the last two - were taken with a Q-Turret Barlow element from Baader at a focal length of approx. 6.500mm. The video module was a Celestron SkyRis 445M in combination with a Baader IrPass filter. For each raw sum image, 2,000 individual images were recorded, of which 10% each were edited. The processing software was AviStack and Photoshop CS 2. The image data can be found in the table. All images are opened in a separate browser window.
Images - SUN
Images - MOON
Images - SOLAR SYSTEM
Images - DEEPSKY
Images - WIDEFIELD
Images - MISCELLANEOUS
Images - SPEC. PROJECTS



Image Number Date Moonage -
Illumination
Formation
01 28.07. 5.3d - 31% Rima Römer, Rima Bond, Lacus Somniorum, Atlas, Herkules, Chacornac, Cepheus, Keldysh, Daniell
02 30.07. 7.3d - 50.5% Rima Ariadaeus, Rima Boskovich, Rima Sosigenes, Cäsar, Dyonisus, Sabine, Ritter, Silberschlag, Boskovich
03 30.07. 7.3d - 50.5% Catena Abulfeda, Tacitus, Almanon, Descartes mit Lunar Swirl
04 30.07. 7.3d - 50.5% Maurolycus, Stöffler und Faraday bei Sonnenaufgang
05 30.07. 7.3d - 50.5% Theophilus, Cyrillus und Catharina
06 02.08. 10.3d - 77.5% Mosaik von Newton, Moretus über Clavius zu Longomontanus
07 31.07. 8.3d - 60% Rima Triesnecker, Rima Hyginus, Rima Boscovich, Ukert und Pyroclastik Mare Vaporum
08 31.07. 8.3d - 60% Maurolycus, Stöffler, Faraday, Nasireddin, Huggins, Orontius, Barocius
09 01.08. 9.3d - 69% Arzachel, Alphonsus und Alpetragius
10 02.08. 10.3d - 77.5% Southpole - Newton, Moretus, Clavius, Blancanus, Longomontanus
11 03.08. 11.3d - 85% Max. Libration. Southpole - Newton, Moretus, Nobile, Scott, Short, Malapert
12 03.08. 11.3d - 85% Moretus, Clavius
13 03.08. 11.3d - 85% Mosaik von Schiller über Mee, Heinzel bis Ramsden, Rima Ramsden
14 05.08. 13.3d - 96% Rima Sirsalis, Rima Riccioli (C14 fokal)
15 06.08. 14.3d - 98.8% Rima Hevelius (C14 fokal) top of page
